McNICHOLS® Stair Treads

Bar Grating, Swage-Locked, Stair Tread, GAL 100, 19-S-4 Spacing, Aluminum, 1" x 3/16" Rectangular Bar, Smooth Surface, Corrugated Angle Nosing, Standard Carrier Plates Attached, 77% Open Area
McNICHOLS® Bar Grating, Swage-Locked, Stair Tread, GAL-100, 19-S-4 Spacing, Aluminum, Alloy Type 6063-T6, Mill Finish, 1" Height x 3/16" Thick Rectangular Bearing Bars, Spaced 1-3/16" on Center with 1" Clear Space Between Bearing Bars, Smooth Surface, Bearing Bars Run Parallel to Length of Stair Tread, Cross Bars Spaced 4" on Center, Corrugated Angle Nosing, Standard End Plates Attached, 77% Open Area

ITEM 670131T336 - 12-1/8" x 36"




Please Request Quote

To use ADD TO PROJECT LIST, please LOG IN as a Registered User.

Item Number 670131T336
Product Line Stair Treads
Main Product Line Bar Grating
Construction Type Swage-Locked
Series Type & Name Bar - GAL-100 (Swage-Locked)
Product Spacing 19-S-4
Primary Material Aluminum (AL)
Alloy, Grade or Type Type 6063-T6 (6063T6)
Material Finish Mill Finish
Bearing Bar Size & Shape 1" x 3/16" Rectangular Bar
Bearing Bar Height 1"
Bearing Bar Thickness 3/16"
Bearing Bar Shape Rectangular Bar
Bearing Bar Spacing 1-3/16" on Center
Clear Space Between Bearing Bars 1"
Product Surface Smooth
Bearing Bar Direction (Span) Parallel to Length of Tread
Cross Bar Type Square Rod
Cross Bar Spacing 4" on Center
Nosing Type Corrugated Angle Nosing
Carrier Plates Attached Yes
Carrier Plate Size View
Percent Open Area 77%
Weight 10.4 Lbs./Tread
Product Form Tread
Sizes (Width x Length) 12-1/8" x 36"
Allowable Sizes View
