McNICHOLS® Stair Treads

Fiberglass Grating, Molded, Stair Tread Panel, MS-R-ST-150, Fiberglass, SGF Polyester Resin, Green, 1-1/2" Grid Height, 1-1/2" x 6" Rectangular Grid, Grit Surface, 1-5/8" Wide Integral Nosing on Both Sides of Tread, 65% Open Area
McNICHOLS® Fiberglass Grating, Molded, Stair Tread Panel, MS-R-ST-150, Fiberglass, SGF Polyester Resin, Green, 1-1/2" Grid Height, 1-1/2" x 6" Rectangular (Interior) Grid, Grit Surface, Long Way of Opening (LWO) Runs Parallel to Length of Stair Tread Panel, 1-5/8" Wide Integral Nosing on Both Sides of Tread Panel Length, 65% Open Area

ITEM F26812TC21 - 22-1/4" x 119-3/4"




Please Request Quote

To use ADD TO PROJECT LIST, please LOG IN as a Registered User.

Item Number F26812TC21
Product Line Stair Treads
Main Product Line Fiberglass Grating
Construction Type Molded
Series Type & Name MS-R-ST-150
Primary Material Fiberglass (FG)
Resin & Type SGF Polyester Resin (SGF)
Color Green
Grid Height 1-1/2"
Grid Size 1-1/2" x 6"
Grid Shape Rectangular
Grid Thickness - Top 1/4"
Grid Thickness - Bottom 13/64"
Product Surface Grit
Long Way of Opening (LWO) Parallel to Length of Tread Panel
Nosing Type 1-5/8" Wide Integral Nosing on Both Sides of Tread Panel Length
Percent Open Area 65%
UV Protection UV Resistant
Fire Retardant Rated Yes
Flame Spread Rating Class A - Per ASTM E-84
Weight 3.20 Lbs./Square Foot
Product Form Tread Panel
Sizes (Width x Length) 22-1/4" x 119-3/4"
Load Table View
