  4. McNICHOLS® Handrail Components Slip-On, Elbow, Aluminum, Aluminum Alloy, No. 9 Side Outlet Elbow, 1.680" Inside Diameter, Fits 1-1/4" Round Pipe (1.660" Outside Diameter)
McNICHOLS® Handrail Components Slip-On, Elbow, Aluminum, Aluminum Alloy, No. 9 Side Outlet Elbow, 1.680" Inside Diameter, Fits 1-1/4" Round Pipe (1.660" Outside Diameter), WH07120
McNICHOLS® Handrail Components Slip-On, Elbow, Aluminum, Aluminum Alloy, No. 9 Side Outlet Elbow, 1.680" Inside Diameter, Fits 1-1/4" Round Pipe (1.660" Outside Diameter), WH07120

McNICHOLS® Handrail Components

Slip-On, Elbow, Aluminum, Aluminum Alloy, No. 9 Side Outlet Elbow, 1.680" Inside Diameter, Fits 1-1/4" Round Pipe (1.660" Outside Diameter)
McNICHOLS® Handrail Components, Slip-On, Elbow, Aluminum, Aluminum Alloy, Mill Finish, No. 9 Side Outlet Elbow, 1.680" Inside Diameter, Fits 1-1/4" Round Pipe (1.660" Outside Diameter)

ITEM WH07120 - Each




Please Request Quote
To use ADD TO PROJECT LIST, please LOG IN as a Registered User.

SPECIFICATIONS

Overview
Ordering

Charts

Tables
Item Number WH07120
Product Line Handrail Components
Attachment Type Slip-On
Component Type Elbow
Primary Material Aluminum (AL)
Alloy, Grade or Type Aluminum Alloy (ALALLY)
Material Finish Mill Finish
Component Profile No. 9 Side Outlet Elbow
Inside Diameter 1.680"
Compatible With Fits 1-1/4" Round Pipe (1.660" Outside Diameter)
Weight 0.57 Lbs./Each
Product Form Each
