855.374.4250 800.237.9212 (español) mcnichols.com GRATINGS CATALOG BAR GRATING PLANK GRATING FIBERGLASS GRATING DECKING & FLOORING 2026 EDITION
Scott McNichols President & CEO The Hole Story!® Robert L. “Bob” McNichols, the sole survivor of a WWII B-17 crash, built his life and business on Christian principles, valuing service, employees, and customers. After being rescued and held at Stalag Luft I POW camp, he was liberated on May 1, 1945. In 1952, Bob and his wife Phyllis founded McNICHOLS CO., focusing on metal products with “holes,” like Perforated and Expanded Metal, inspiring the motto “The Hole Story.” Trademarked in 1975, it began a tradition of playful “hole” references throughout the Company. After Bob passed in 1981, his son Gene took over and introduced the mission “Service, Quality and Performance.” Today, McNICHOLS remains a family business with 19 locations nationwide. Bob’s faith and his saying, “To God be the Glory,” continue to inspire the Hole Team, now guided by the third generation. Our Mission: Provide Hole Products Through Superior Service, Quality, and Performance… That’s The Hole Story! Dear Hole Customer, Thank you for the opportunity to share The Hole Story with you. Over seventy years ago, my grandfather founded our business, and our mission remains the same: exceptional service every time. We’re committed to providing the best Specialty Metals resources. Our customers rely on the McNICHOLS® Gratings Catalog and mcnichols.com to find the right Hole Products. We understand the need to adapt and earn your trust. On behalf of all McNICHOLS associates, I humbly ask for the chance to serve you and show you what it means to be Inspired to Serve!® Robert L. “Bob” McNichols Lieutenant, United States Army Air Corps 1970 1944 Learn more at mcnichols.com/about-us
1 855.374.4250 What’s Inside ©1989-2026 McNICHOLS CO., McNICHOLS, The Hole Story, Inspired to Serve and ECO-MESH are registered trademarks of McNICHOLS CO. All rights reserved. No part of this book may be reproduced in any form without written permission by a Company officer. This catalog is printed in the USA. Application photos shown are typical of our types of products in use that can be supplied or have been supplied by McNICHOLS CO. Photos may depict uses designed, manufactured, fabricated or installed by others. Photos within are not to scale unless otherwise specified. Bar Grating 2 Bar Grating Resources 4 Standard-Duty Welded Rectangular Bar 6 GW & SGW Series 6 CMW-4 Series CLOSE MESH 6 Heavy-Duty Welded Rectangular Bar 8 GHB Series 8 PEDS & TREADS® 8 Swage-Locked Rectangular Bar 10 GAL & SGAL Series 10 SFT Series 10 Swage-Locked I-Bar 12 GIA & SGIA Series 12 Swage-Locked T-Bar 14 SAFE-T-GRID® 14 Press-Locked Rectangular Bar 16 GCM Series CLOSE MESH 16 GAA, GBB, GCC & GDD Series 16 Stair Treads 18 Accessories 22 Heavy-Duty Vehicular Load Table 23 Plank Grating 24 Plank Grating Resources 26 GRIP STRUT® Plank 28 GRIP STRUT® Walkway 29 HEAVY-DUTY GRIP STRUT® Plank 30 HEAVY-DUTY GRIP STRUT® Walkway 30 PERF-O GRIP® Plank 31 PERF-O GRIP® Walkway 32 TRACTION TREAD™ Plank 32 GRATE-LOCK® Interlocking Plank 33 DIAMONDBACK® Extruded Interlocking Plank 33 HD-EXT - Heavy-Duty Extruded Plank 34 Ladder Rungs & Covers 34 Stair Treads 35 Accessories 39 Fiberglass Grating 40 Fiberglass Grating Resources 42 Square Molded 44 Square Grid (MS-S) 44 Square Grid (MS-M-150 - MINI-GRID®) 44 Rectangular Molded 45 Rectangular Grid (MS-R) 45 Pultruded I-Bar 46 MS-I-4000 Series 46 MS-I-6000 Series 46 MS-I-6500 Series 46 Phenolic Grating 46 Pultruded T-Bar 47 MS-T-3000 Series 47 MS-T-5000 Series 47 Pultruded Wide T-Bar 48 MS-WT Series 48 Decking & Flooring 50 Metal Flooring 51 POLYCAST® Trench Drain System 51 Stair Treads 52 Accessories 54 Fiberglass Resin Options 55 McNICHOLS® Nationwide Locations 57 Understanding Load Tables McNICHOLS® load tables help you select the right Grating solution based on load capacity, clear span, and deflection limits. Whether you are getting started or just need a refresher, scan the QR code to learn more. McNICHOLS® GRIP STRUT® Black Powder Coat Finish No. 26052012 McNICHOLS® Wire Mesh Infill Panels Black Powder Coat Finish No. 36932500
2 855.374.4250 McNICHOLS® Bar Grating McNICHOLS® Bar Grating brings safety, strength, and durability to industrial and architectural applications and is regularly installed on bridges, factory floors, platforms, and as Stair Treads. Bar Grating is a high-performance, low-maintenance product capable of handling pedestrian or vehicular loads. Openings allow air, light, sound, and fluid to pass, while many surface profiles offer slip-resistant properties. STANDARD-DUTY WELDED HEAVY-DUTY WELDED SWAGE-LOCKED PRESS-LOCKED STAIR TREADS How to Specify & Order 1. Choose between Standard-Duty Welded, Heavy-Duty Welded, Swage-Locked, Press-Locked, or Clinched construction types. 2. Determine the series type and name (GW-100, GHB-150, GAL-125, etc.) of the product for your project, including ADA-compliant items, if necessary. 3. Pick Aluminum (AL), Carbon Steel (CS) (Powder Coated available), Galvanized Steel (GV), or Stainless Steel (SS). Inventory is typically mill finish. 4. Specify the product spacing (e.g., 19-W-4) for your project. The first number (19) refers to the bearing bar spacing measured on center (19/16” or 1-3/16”). The last number (4) references the cross bar spacing measured on center. 5. Select the height, thickness, and surface (smooth, serrated, grooved) of the bearing bars, and choose from Rectangular Bar, I-Bar, and T-Bar shapes. 6. Select the direction the bearing bars need to run to properly support the load (span). See illustration below for more information on span. Important Considerations Understanding how span, direction of travel, and load types affect Bar Grating is essential to ensuring its safety, performance, and structural integrity in any application. UNDERSTANDING SPAN & DIRECTION OF TRAVEL Span refers to the distance between supports, and it’s critical that the bearing bars run parallel to them, regardless of the direction of traffic. Incorrect orientation can compromise strength and safety. Bar Grating should be installed so the bearing bars span the shortest distance between supports— regardless of direction of travel. Whether covering a trench drain or building a walkway, proper Grating alignment is key. When designing with Bar Grating, it is essential to consider the type of load being applied. Uniform Loads (evenly distributed weight) and Concentrated Loads (weight concentrated in a specific area) are important design considerations. Selecting the correct load type ensures optimal performance and safety. Our experts can guide you in selecting the Grating solution based on your specific load conditions, ensuring structural integrity. Bearing bars run width of the trench, supports run length of the trench. Deflection Uniform Load (“U”) Clear Span Concentrated Load (“C”) SELECTING YOUR LOAD TYPE
BAR GRATING 3 mcnichols.com McNICHOLS® Bar Grating Galvanized Stair Treads with Checkered Plate Nosing APPLICATIONS Access Platforms Bridges Catwalks Fencing Gangways Industrial Flooring Loading Docks Machine Platforms Stair Treads Substations Trench Covers/Grates Walkways Work Platforms NORTH AMERICAN ASSOCIATION OF METAL MANUFACTURERS (NAAMM) All of our Bar Grating products are produced and fabricated to NAAMM fabrication standards. McNICHOLS® is a proud member of the American Welding Society.
4 855.374.4250 NOTCHING, SKEW CUTTING, AND RADIUS CUTS We offer notching, skew cutting, and circular cuts to ensure a perfect fit for your Bar Grating needs. Precise skew and circular cuts accommodate angled surfaces, pipes, and rounded structures. Notching Skew Cutting Radius Cuts CUSTOM KICK PLATES Kick Plates are a crucial safety feature for elevated Grating surfaces, providing edge protection that helps prevent tools, materials, and equipment from being accidentally displaced and creating hazards. VALUE-ADDED SERVICES McNICHOLS® Fabrication & Technical Support Our focus on Value-Added Services and prefabricated materials helps save time and preserve floor space, allowing you to stay focused on the core demands of the job. From accurate estimates and optimized material yield to expert grating solutions that support both function and cost-efficiency, we help move projects forward with confidence. Project requirements are translated into install-ready components, fabricated to specification to help reduce shop and field labor. APPROVAL DRAWINGS FOR ACCURATE FABRICATION Our Structural Design Specialists supply approval drawings as part of the ordering process, giving you the confidence that everything is in order before fabrication. These detailed drawings help to provide you with a clear, precise visual of your design with accuracy and proper alignment. Our team works closely with you to ensure that any adjustments or specific requirements are incorporated, ensuring the final product meets your needs. TRIM & LOAD BANDING Banding is used to close the open ends of bearing bars and enhance both appearance and handling. Trim banding is welded to the first two bars, then every four to six bars, while load banding is welded to each bearing bar to support heavier load-bearing applications. Trim Banding Load Banding SHEARING OPTIONS Uniform or Equal Shear are typically preferred where visual consistency is important, creating cleaner alignment for architectural applications. Random Shear is often specified for industrial use as a more economical option where appearance is secondary to performance. Random Uniform Equal INSTALLATION HIGHLIGHT: TRENCH DRAINS When Bar Grating is used for trench drain applications, proper Grating alignment and installation is key, especially in areas encountering heavy loads. Click the play button to see a quick visual of how Bar Grating is installed and functions in this application.
BAR GRATING 5 mcnichols.com Cross Bar Spacing Bearing Bar Height Bearing Bar Spacing Bearing Bar Thickness Space between Bearing Bars Terminology & Resources Bar Grating Standard Product & Sawing Tolerances BAR GRATING TOLERANCES CONSTRUCTION TYPE BEARING BAR SHAPE SQUARENESS TOLERANCE FLATNESS TOLERANCE SAWING TOLERANCE DIFF. IN DIAG. DIMENSIONS WIDTH LENGTH WIDTH LENGTH STANDARD-DUTY WELDED RECTANGULAR BAR +/- 1/4" 1/8" PER FOOT OF WIDTH 1/200 OF SPAN +/- ONE BEARING BAR +/- 1/4" HEAVY-DUTY WELDED RECTANGULAR BAR +/- 1/4" 1/8" PER FOOT OF WIDTH 1/200 OF SPAN +/- ONE BEARING BAR +/- 1/4" SWAGE-LOCKED RECT. BAR, I-BAR, T-BAR +/- 1/4" 1/8" PER FOOT OF WIDTH 1/200 OF SPAN +/- ONE BEARING BAR +/- 1/4" PRESS-LOCKED RECTANGULAR BAR +/- 1/4" 1/8" PER FOOT OF WIDTH 1/200 OF SPAN +/- ONE BEARING BAR +/- 1/4" Due to the differences in primary material types (e.g. Aluminum, Stainless Steel, etc.), some tolerances may vary slightly from those listed above. For Bar Grating trench applications, the dimensional tolerance is +/- bearing bar along the width dimension and + 0/ - 1/4" along the length dimension. Technical information provided is for evaluation by technically skilled persons, with any use thereof to be at their independent discretion and risk. McNICHOLS shall have no responsibility or liability for results obtained or damages resulting from improper evaluation or use of Bar Grating. Bearing Bar Height • Also known as bearing bar depth, is measured from the bottom of the bearing bar to the top surface. Bearing Bar Spacing • The distance from the center of one bearing bar to the center of the next adjacent bearing bar. Bearing Bar Thickness • Also known as Bearing Bar Width, is the measurement of distance between the left surface of the bearing bar to the right surface of the same bearing bar. Cross Bar Spacing • The distance from the center of one cross bar to the center of the next cross bar. Space Between Bearing Bars • The distance between bearing bars. For more information on Bar Grating, please visit mcnichols.com/resources where you’ll find detailed resources, specifications, and purchasing options. PANEL TOLERANCES To help ensure proper fit and reliable performance, Bar Grating panels are specified within tolerance guidelines. Understanding the allowable variations in length, width, and squareness supports successful installation and long-term structural integrity. INSTALLATION CLEARANCES We work closely with you to ensure your design accounts for the required clearance, providing precise takeoffs to confirm that your grating will fit seamlessly. 3/8” 3/8” SD – Standard-Duty HD – Heavy-Duty LONGITUDINAL BOW Slight curvature that may occur along the length of a panel and typically corrects itself during installation when properly fastened to supports. SD – 1/200 OF L | HD – 1/240 OF L SD – 1/200 OF L | HD – 1/240 OF L TRAVERSE BOW Slight curvature that can occur across the width of a panel and is typically resolved during installation with proper anchoring. 1/8” PER FOOT OF W 1/8” PER FOOT OF W SD – D +/– 1/32” HD – D +/– 1/16” SD – D +/– 1/4” HD – D +/– 3/8” SD – D +/– 1/4” HD – D +/– 3/8” W +/– 1/4” L +/– 1/4” 1/8” 1/8”
6 855.374.4250 BEARING BAR PANEL WIDTHS NO. BARS GW, GW-2 SGW, SGW-2 CMW-4 1/8" 3/16" 1/8" 3/16" 1/8" 3/16" 2 1-5/16" 1-3/8" 1-1/16" 1-1/8" 13/16" 7/8" 3 2-1/2" 2-9/16" 2" 2-1/16" 1-1/2" 1-9/16" 4 3-11/16" 3-3/4" 2-15/16" 3" 2-3/16" 2-1/4" 5 4-7/8" 4-15/16" 3-7/8" 3-15/16" 2-7/8" 2-15/16" 6 6-1/16" 6-1/8" 4-13/16" 4-7/8" 3-9/16" 3-5/8" 7 7-1/4" 7-5/16" 5-3/4" 5-13/16" 4-1/4" 4-5/16" 8 8-7/16" 8-1/2" 6-11/16" 6-3/4" 4-15/16" 5" 9 9-5/8" 9-11/16" 7-5/8" 7-11/16" 5-5/8" 5-11/16" 10 10-13/16" 10-7/8" 8-9/16" 8-5/8" 6-5/16" 6-3/8" 11 12" 12-1/16" 9-1/2" 9-9/16" 7" 7-1/16" 12 13-3/16" 13-1/4" 10-7/16" 10-1/2" 7-11/16" 7-3/4" 13 14-3/8" 14-7/16" 11-3/8" 11-7/16" 8-3/8" 8-7/16" 14 15-9/16" 15-5/8" 12-5/16" 12-3/8" 9-1/16" 9-1/8" 15 16-3/4" 16-13/16" 13-1/4" 13-5/16" 9-3/4" 9-13/16" 16 17-15/16" 18" 14-3/16" 14-1/4" 10-7/16" 10-1/2" 17 19-1/8" 19-3/16" 15-1/8" 15-3/16" 11-1/8" 11-3/16" 18 20-5/16" 20-3/8" 16-1/16" 16-1/8" 11-13/16" 11-7/8" 19 21-1/2" 21-9/16" 17" 17-1/16" 12-1/2" 12-9/16" 20 22-11/16" 22-3/4" 17-15/16" 18" 13-3/16" 13-1/4" 21 23-7/8" 23-15/16" 18-7/8" 18-15/16" 13-7/8" 13-15/16" 22 25-1/16" 25-1/8" 19-13/16" 19-7/8" 14-9/16" 14-5/8" 23 26-1/4" 26-5/16" 20-3/4" 20-13/16" 15-1/4" 15-5/16" 24 27-7/16" 27-1/2" 21-11/16" 21-3/4" 15-15/16" 16" 25 28-5/8" 28-11/16" 22-5/8" 22-11/16" 16-5/8" 16-11/16" 26 29-13/16" 29-7/8" 23-9/16" 23-5/8" 17-5/16" 17-3/8" 27 31" 31-1/16" 24-1/2" 24-9/16" 18" 18-1/16" 28 32-3/16" 32-1/4" 25-7/16" 25-1/2" 18-11/16" 18-3/4" 29 33-3/8" 33-7/16" 26-3/8" 26-7/16" 19-3/8" 19-7/16" 30 34-9/16" 34-5/8" 27-5/16" 27-3/8" 20-1/16" 20-1/8" 31 35-3/4" 35-13/16" 28-1/4" 28-5/16" 20-3/4" 20-13/16" 32 -- -- 29-3/16" 29-1/4" 21-7/16" 21-1/2" 33 -- -- 30-1/8" 30-3/16" 22-1/8" 22-3/16" 34 -- -- 31-1/16" 31-1/8" 22-13/16" 22-7/8" 35 -- -- 32" 32-1/16" 23-1/2" 23-9/16" 36 -- -- 32-15/16" 33" 24-3/16" 24-1/4" 37 -- -- 33-7/8" 33-15/16" 24-7/8" 24-15/16" 38 -- -- 34-13/16" 34-7/8" 25-9/16" 25-5/8" 39 -- -- 35-3/4" 35-13/16" 26-1/4" 26-5/16" 40 -- -- -- -- 26-15/16" 27" 41 -- -- -- -- 27-5/8" 27-11/16" 42 -- -- -- -- 28-5/16" 28-3/8" 43 -- -- -- -- 29" 29-1/16" 44 -- -- -- -- 29-11/16" 29-3/4" 45 -- -- -- -- 30-3/8" 30-7/16" 46 -- -- -- -- 31-1/16" 31-1/8" 47 -- -- -- -- 31-3/4" 31-13/16" 48 Common widths listed in gray. All others are cut sizes. Panels are measured from outside edges of bearing bars. Panels up to 48" wide are available by custom order. Wider areas are covered by two or more pieces of Grating. 32-7/16" 32-1/2" 49 33-1/8" 33-3/16" 50 33-13/16" 33-7/8" 51 34-1/2" 34-9/16" 52 35-3/16" 35-1/4" 53 35-7/8" 35-15/16" GW, GW-2 STEEL LOAD TABLE BB HGT BB THK LD/DF 12" 18" 24" 30" 36" 42" 48" 54" 60" 66" 72" 78" 84" 90" 96" 3/4" 1/8" U 1421 631 355 227 158 116 89 70 57 47 39 34 29 25 22 D 0.025 0.056 0.099 0.155 0.224 0.304 0.398 0.502 0.623 0.752 0.883 1.061 1.217 1.382 1.575 C 710 474 355 284 237 203 178 158 142 129 118 109 101 95 89 D 0.020 0.045 0.079 0.124 0.179 0.243 0.319 0.403 0.496 0.600 0.713 0.837 0.969 1.121 1.274 3/4" 3/16" U 2131 947 533 341 237 174 133 105 85 70 59 50 43 38 33 D 0.025 0.056 0.099 0.155 0.224 0.304 0.397 0.502 0.619 0.746 0.891 1.040 1.203 1.401 1.575 C 1066 710 533 426 355 304 266 237 213 194 178 164 152 142 133 D 0.020 0.045 0.079 0.124 0.179 0.243 0.317 0.403 0.496 0.602 0.717 0.839 0.972 1.117 1.269 1" 1/8" U 2526 1123 632 404 281 206 158 125 101 84 70 60 52 45 39 D 0.019 0.042 0.075 0.116 0.168 0.228 0.298 0.378 0.465 0.566 0.668 0.789 0.920 1.049 1.177 C 1263 842 632 505 421 361 316 281 253 230 211 194 180 168 158 D 0.015 0.034 0.060 0.093 0.134 0.182 0.238 0.302 0.373 0.451 0.537 0.628 0.728 0.836 0.954 1" 3/16" U 3790 1684 947 606 421 309 237 187 152 125 105 90 77 67 59 D 0.019 0.042 0.074 0.116 0.168 0.228 0.298 0.377 0.467 0.562 0.669 0.789 0.908 1.042 1.187 C 1895 1263 947 758 632 541 474 421 379 345 316 292 271 253 237 D 0.015 0.034 0.060 0.093 0.134 0.182 0.238 0.302 0.372 0.451 0.537 0.630 0.731 0.839 0.954 1-1/4" 1/8" U 3947 1754 987 631 439 322 247 195 158 130 110 93 81 70 62 D 0.015 0.034 0.060 0.093 0.134 0.182 0.239 0.302 0.373 0.449 0.538 0.626 0.734 0.836 0.958 C 1973 1316 987 789 658 564 493 439 395 359 329 304 282 263 247 D 0.012 0.027 0.048 0.074 0.107 0.146 0.191 0.242 0.298 0.361 0.429 0.504 0.584 0.670 0.764 1-1/4" 3/16" U 5921 2631 1480 947 658 483 370 292 237 196 164 140 121 105 93 D 0.015 0.034 0.060 0.093 0.134 0.182 0.238 0.301 0.373 0.451 0.535 0.629 0.731 0.836 0.958 C 2960 1974 1480 1184 987 846 740 658 592 538 493 455 423 395 370 D 0.012 0.027 0.048 0.074 0.107 0.146 0.191 0.241 0.298 0.360 0.429 0.503 0.584 0.671 0.763 1-1/2" 1/8" U 5684 2526 1421 910 632 464 355 281 227 188 158 135 116 101 89 D 0.012 0.028 0.050 0.078 0.112 0.152 0.198 0.252 0.310 0.376 0.447 0.526 0.608 0.698 0.796 C 2842 1895 1421 1137 947 812 711 632 568 517 474 437 406 379 355 D 0.010 0.022 0.040 0.062 0.089 0.122 0.159 0.201 0.248 0.301 0.358 0.419 0.487 0.559 0.635 1-1/2" 3/16" U 8526 3789 2132 1364 947 696 533 421 341 282 237 202 174 152 133 D 0.012 0.028 0.050 0.078 0.112 0.152 0.199 0.251 0.310 0.376 0.447 0.525 0.608 0.700 0.793 C 4263 2842 2132 1705 1421 1218 1066 947 853 775 711 656 609 568 533 D 0.010 0.022 0.040 0.062 0.089 0.122 0.159 0.201 0.248 0.300 0.358 0.420 0.487 0.558 0.636 1-3/4" 3/16" U 11605 5158 2901 1857 1289 947 725 573 464 384 322 275 237 206 181 D 0.011 0.024 0.043 0.067 0.096 0.130 0.170 0.215 0.266 0.322 0.383 0.450 0.522 0.598 0.680 C 5803 3868 2901 2321 1934 1658 1451 1289 1161 1055 967 893 829 774 725 D 0.009 0.019 0.034 0.053 0.077 0.104 0.136 0.172 0.213 0.257 0.306 0.360 0.417 0.479 0.545 2" 3/16" U 15158 6737 3790 2425 1684 1237 947 749 606 501 421 359 309 269 237 D 0.009 0.021 0.037 0.058 0.084 0.114 0.149 0.189 0.233 0.282 0.335 0.394 0.456 0.523 0.596 C 7579 5053 3790 3032 2526 2165 1895 1684 1516 1378 1263 1166 1083 1011 947 D 0.007 0.017 0.030 0.047 0.067 0.091 0.119 0.151 0.186 0.225 0.268 0.315 0.365 0.419 0.476 2-1/4" 3/16" U 19184 8526 4796 3070 2132 1566 1199 947 767 634 533 454 392 341 300 D 0.008 0.019 0.033 0.052 0.074 0.101 0.132 0.168 0.207 0.250 0.298 0.350 0.406 0.465 0.530 C 9592 6395 4796 3837 3197 2741 2398 2132 1918 1744 1599 1476 1370 1279 1199 D 0.007 0.015 0.026 0.041 0.060 0.081 0.106 0.134 0.165 0.200 0.238 0.280 0.324 0.372 0.424 2-1/2" 3/16" U 23684 10526 5921 3790 2632 1933 1480 1170 947 783 658 561 483 421 370 D 0.007 0.017 0.030 0.047 0.067 0.091 0.119 0.151 0.186 0.225 0.268 0.315 0.365 0.419 0.477 C 11842 7895 5921 4737 3947 3383 2961 2632 2368 2153 1974 1822 1692 1579 1480 D 0.006 0.013 0.024 0.037 0.054 0.073 0.095 0.121 0.149 0.180 0.215 0.252 0.292 0.335 0.381 CONVERSION FACTOR For SGW, SGW-2 and CMW-4 loads, multiply values by factors to right. Deflection results will not change. SGW, SGW-2 1.27 CMW-4 1.73 U - Uniform Load - Lbs./Sf. D - Deflection in Inches C - Concentrated Load - Lbs./Ft. of Width at Mid-Span Fs - 18,000 PSI E - 29,000,000 PSI | Additional information at mcnichols.com. Spans listed in table are clear (inside structural supports). Values to left of bolded black line produce deflection < 1/4" under a uniform load of 100 Lbs./Sf., allowing for safe pedestrian comfort. Values to right apply to other load types at discretion of engineer. SGW, SGW-2 and CMW-4 Series 1/4" deflection information is available at mcnichols.com. For 1" height and taller serrated surface bars, subtract 1/4" from bar height and reference that loading information in table (e.g., 1-1/2" height x 3/16" thick serrated bar has same loading as 1-1/4" height x 3/16" thick smooth bar). CMW-4 Series with 3/16" thick bars is ADA compliant. Technical information is theoretical. McNICHOLS is not liable for improper evaluation or use of Bar Grating. SERIES GW, GW-2, SGW, SGW-2 MATERIAL M ill Finish: Carbon Steel (CS) (Plain, Powder Coated Black, Gray), Galvanized Steel (GV), Stainless Steel (SS) SURFACE Smooth, Serrated | GRIP TIGHT® SIZE (W x L) 2 4” x 240”, 24” x 288”, 36” x 120”, 36” x 240”, 36” x 288”, Other Sizes, Cut Sizes, Stair Treads Available SERIES CMW-4 – CLOSE MESH MATERIAL M ill Finish: Carbon Steel (CS), Galvanized Steel (GV), Stainless Steel (SS) SURFACE Smooth | Serrated, GRIP TIGHT® SIZE (W x L) 2 4” x 240”, 24” x 288”, 36” x 120”, 36” x 240”, 36” x 288”, Other Sizes, Cut Sizes, Stair Treads Available McNICHOLS® Standard-Duty Rectangular Bar Grating A suitable flooring application choice because of its strength, safety, and overall value. CUSTOM ORDER CUSTOM ORDER SERIES, SPACING GW 19-W-4 GW-2 19-W-2 SGW 15-W-4 SGW-2 15-W-2 CMW-4 11-W-4 CMW-4 11-W-2 BB SPACING 1-3/16” 1-3/16” 15/16” 15/16” 11/16” 11/16” CB SPACING 4” 2” 4” 2” 4” 2” BB THK 1/8” 3/16” 1/8” 3/16” 1/8” 3/16” 1/8” 3/16” 1/8” 3/16” 1/8” 3/16” SPACE B/T BB 1-1/16” 1” 1-1/16” 1” 3/16” 3/4” 3/16” 3/4” 9/16” 1/2” (ADA) 9/16” 1/2” (ADA) OA % 83% 77% 76% 71% 77% 70% 71% 64% 79% 70% 76% 68% PRODUCT OPTIONS BB HGT CS CS CS CS CS CS 3/4" 4.1 5.8 5.0 6.7 5.0 7.2 5.9 8.1 6.2 9.1 – – 1" 5.2 7.5 6.1 8.4 6.4 9.3 7.3 10.2 8.1 11.9 8.6 12.5 1-1/4" 6.3 9.1 7.2 10.0 7.9 11.3 8.8 12.2 10.0 14.7 10.5 15.3 1-1/2" 7.4 10.8 8.3 11.7 9.3 13.5 10.2 14.4 11.9 17.5 12.4 18.1 1-3/4" – 12.5 – 13.4 – 15.6 – 16.5 – 20.4 – 21.0 2" – 14.1 – 15.0 – 17.7 – 18.6 – 23.2 – 23.8 2-1/4" – 15.8 – 16.7 – 19.8 – 20.7 – 26.0 – 26.6 2-1/2" – 17.4 – 18.3 – 21.9 – 22.8 – 28.8 – 29.4 LBS PER SQ FT
BAR GRATING 7 mcnichols.com McNICHOLS® Standard-Duty Welded Bar Grating, GW-100 (19-W-4), No. 66013101 Grating Description: GW-100 (19-W-4) Bar Grating names follow a standard format. Each part of the name provides key details about the Grating’s structure. The guide below breaks down the naming convention with an example to help you quickly interpret specifications. 19-W-4 GW-100 Grating Type Description 19 W 4 GW 100 19/16” (1-3/16”) BB Spacing Welded Construction Type 4” CB Spacing Grating Welded Series Type 1” BB Height Visit mcnichols.com to browse our entire inventory of GW, SGW, and CMW Standard-Duty Bar Grating. BB Thickness BB Spacing CB END VIEW Smooth Serrated GRIP TIGHT® SURFACE TYPES Carbon Steel Black Powder Coat Galvanized Steel Gray Powder Coat Stainless Steel FINISHES CB Spacing BB Height SIDE VIEW CUSTOM ORDER
8 855.374.4250 BB HGT BB THK LD/DF 12" 18" 24" 30" 36" 42" 48" 54" 60" 66" 72" 78" 84" 90" 96" GHB, GHB-2 STEEL LOAD TABLE 1" 1/4" U 5615 2495 1404 898 624 458 351 277 225 186 156 133 115 100 88 D 0.021 0.047 0.083 0.129 0.186 0.253 0.331 0.419 0.518 0.627 0.745 0.875 1.018 1.166 1.329 C 2807 1872 1404 1123 936 802 702 624 561 510 468 432 401 374 351 D 0.017 0.037 0.066 0.103 0.149 0.203 0.265 0.335 0.414 0.500 0.596 0.700 0.811 0.930 1.060 1-1/4" 1/4" U 8772 3899 2193 1404 975 716 548 433 351 290 244 208 179 156 137 D 0.017 0.037 0.066 0.103 0.149 0.203 0.265 0.335 0.414 0.501 0.597 0.701 0.811 0.931 1.059 C 4386 2924 2193 1754 1462 1253 1097 975 877 797 731 675 627 585 548 D 0.013 0.030 0.053 0.083 0.119 0.162 0.212 0.268 0.331 0.400 0.477 0.560 0.649 0.745 0.847 1-1/2" 1/4" U 12632 5614 3158 2021 1404 1031 790 624 505 418 351 299 258 225 197 D 0.014 0.031 0.055 0.086 0.124 0.169 0.221 0.279 0.345 0.418 0.497 0.583 0.676 0.777 0.881 C 6316 4211 3158 2526 2105 1805 1579 1404 1263 1148 1053 972 902 842 790 D 0.011 0.025 0.044 0.069 0.099 0.135 0.177 0.224 0.276 0.334 0.397 0.466 0.541 0.621 0.707 1-3/4" 1/4" U 17193 7641 4298 2751 1910 1404 1075 849 688 568 478 407 351 306 269 D 0.012 0.027 0.047 0.074 0.106 0.145 0.189 0.239 0.296 0.357 0.426 0.500 0.580 0.666 0.758 C 8597 5731 4298 3439 2866 2456 2149 1910 1719 1563 1433 1323 1228 1146 1075 D 0.009 0.021 0.038 0.059 0.085 0.116 0.151 0.191 0.236 0.286 0.341 0.400 0.463 0.532 0.606 2" 1/4" U 22456 9980 5614 3593 2495 1833 1404 1109 898 742 624 532 458 399 351 D 0.010 0.023 0.041 0.065 0.093 0.127 0.166 0.209 0.259 0.313 0.373 0.437 0.507 0.582 0.662 C 11228 7485 5614 4491 3743 3208 2807 2495 2246 2041 1871 1727 1604 1497 1404 D 0.008 0.019 0.033 0.052 0.074 0.101 0.132 0.168 0.207 0.250 0.298 0.350 0.406 0.465 0.530 2-1/4" 1/4" U 28421 12632 7105 4547 3158 2320 1776 1404 1137 940 789 673 580 505 444 D 0.009 0.021 0.037 0.057 0.083 0.113 0.147 0.186 0.230 0.278 0.331 0.389 0.451 0.517 0.588 C 14211 9474 7105 5684 4737 4060 3553 3158 2842 2584 2368 2186 2030 1895 1776 D 0.007 0.017 0.029 0.046 0.066 0.090 0.118 0.149 0.184 0.223 0.265 0.311 0.360 0.414 0.471 2-1/2" 1/4" U 35088 15595 8772 5614 3899 2864 2193 1733 1404 1160 975 830 716 624 548 D 0.008 0.019 0.033 0.052 0.074 0.101 0.132 0.168 0.207 0.250 0.298 0.349 0.405 0.466 0.529 C 17544 11696 8772 7018 5848 5013 4386 3899 3509 3190 2924 2699 2506 2339 2193 D 0.007 0.015 0.026 0.041 0.060 0.081 0.106 0.134 0.166 0.200 0.238 0.280 0.324 0.372 0.424 3" 1/4" U 50527 22456 12632 8084 5614 4125 3158 2495 2021 1670 1404 1196 1031 898 789 D 0.007 0.016 0.028 0.043 0.062 0.084 0.110 0.140 0.172 0.209 0.248 0.291 0.338 0.388 0.441 C 25263 16842 12632 10105 8421 7218 6316 5614 5053 4593 4211 3887 3609 3368 3158 D 0.006 0.012 0.022 0.034 0.050 0.068 0.088 0.112 0.138 0.167 0.199 0.233 0.270 0.310 0.353 3-1/2" 1/4" U 68772 30565 17193 11004 7641 5614 4298 3396 2751 2273 1910 1628 1404 1223 1075 D 0.006 0.013 0.024 0.037 0.053 0.072 0.095 0.120 0.148 0.179 0.213 0.250 0.290 0.333 0.378 C 34386 22924 17193 13754 11462 9825 8597 7641 6877 6252 5731 5290 4912 4585 4298 D 0.005 0.011 0.019 0.030 0.043 0.058 0.076 0.096 0.118 0.143 0.170 0.200 0.232 0.266 0.303 4" 1/4" U 89825 39922 22456 14372 9981 7333 5614 4436 3593 2969 2495 2126 1833 1597 1404 D 0.005 0.012 0.021 0.032 0.047 0.063 0.083 0.105 0.129 0.156 0.186 0.219 0.253 0.291 0.331 C 44913 29942 22456 17965 14971 12832 11228 9981 8983 8166 7485 6910 6416 5988 5614 D 0.004 0.009 0.017 0.026 0.037 0.051 0.066 0.084 0.103 0.125 0.149 0.175 0.203 0.233 0.265 CONVERSION FACTOR For GHB and GHB-2 loads with 5/16" or 3/8" bars, multiply values by factors to right. Deflection results will not change. 5/16" BAR 1.25 3/8" BAR 1.50 U - Uniform Load - Lbs./Sf. D - Deflection in Inches C - Concentrated Load - Lbs./Ft. of Width at Mid-Span Fs - 20,000 PSI E - 29,000,000 PSI | Additional information at mcnichols.com. Spans listed in table are clear (inside structural supports). Values to left of bolded black line produce deflection < 1/4" under a uniform load of 100 Lbs./Sf., allowing for safe pedestrian comfort. Values to right apply to other load types at discretion of engineer. GHB and GHB-2 Series 1/4" deflection information for 5/16" and 3/8" thick bearing bars is available at mcnichols.com. For 1" height and taller serrated surface bars, subtract 1/4" from bar height and reference that loading information in table (e.g., 1-1/2" height x 1/4" thick serrated bar has same loading as 1-1/4" height x 1/4" thick smooth bar). GHB and GHB-2 Grating is not usually selected for standard floor layouts, but is typically chosen for rolling or vehicular loads for narrow space work. Technical information is theoretical. McNICHOLS is not liable for improper evaluation or use of Bar Grating. GHB SERIES PANEL WIDTHS NO. BARS GHB, GHB-2 1/4" BAR 5/16" BAR 3/8" BAR 2 1-7/16" 1-1/2" 1-9/16" 3 2-5/8" 2-11/16" 2-3/4" 4 3-13/16" 3-7/8" 3-15/16" 5 5" 5-1/16" 5-1/8" 6 6-3/16" 6-1/4" 6-5/16" 7 7-3/8" 7-7/16" 7-1/2" 8 8-9/16" 8-5/8" 8-11/16" 9 9-3/4" 9-13/16" 9-7/8" 10 10-15/16" 11" 11-1/16" 11 12-1/8" 12-3/16" 12-1/4" 12 13-5/16" 13-3/8" 13-7/16" 13 14-1/2" 14-9/16" 14-5/8" 14 15-11/16" 15-3/4" 15-13/16" 15 16-7/8" 16-15/16" 17" 16 18-1/16" 18-1/8" 18-3/16" 17 19-1/4" 19-5/16" 19-3/8" 18 20-7/16" 20-1/2" 20-9/16" 19 21-5/8" 21-11/16" 21-3/4" 20 22-13/16" 22-7/8" 22-15/16" 21 24" 24-1/16" 24-1/8" 22 25-3/16" 25-1/4" 25-5/16" 23 26-3/8" 26-7/16" 26-1/2" 24 27-9/16" 27-5/8" 27-11/16" 25 28-3/4" 28-13/16" 28-7/8" 26 29-15/16" 30" 30-1/16" 27 31-1/8" 31-3/16" 31-1/4" 28 32-5/16" 32-3/8" 32-7/16" 29 33-1/2" 33-9/16" 33-5/8" 30 34-11/16" 34-3/4" 34-13/16" 31 35-7/8" 35-15/16" 36" Common widths listed in gray. All others are cut sizes. Panels are measured from outside edges of bearing bars. Panels up to 48" wide are available by custom order. Wider areas are covered by two or more pieces of Grating. SERIES, SPACING GHB 19-W-4 GHB-2 19-W-2 8-PT-4 12-PT-4 PT-250 PT-500 BB SPACING 1-3/16” 1-3/16” 1/2” 3/4” 15/16” 1-3/8” CB SPACING 4” 2” 4” 4” 4” 4” BB THK 1/4” 5/16” 3/8” 1/4” 5/16” 3/8” 1/4” 1/4” 1/4” (3/16” Fill) 1/4” (1/8” Fill) SPACE B/T BB 15/16” 7/8” 13/16” 15/16” 7/8” 13/16” 1/4” (ADA) 1/2” (ADA) 1/4” (ADA) 1/2” (ADA) OA % 71%* 73%* 69% 64% 64%* 68%* 61% 56% 44%* 45%* 59%* 60%* 47%* 48%* 60%* 61%* PRODUCT OPTIONS *Cross bar thicknesses and shapes vary by bearing bar height and material, see mcnichols.com for more information. BB HGT CS CS CS CS CS CS CS CS 1" – 9.8 11.9 14.0 – 10.7 12.7 14.9 – 21.5 – 14.7 – – – – 1-1/4" – 12.0 14.6 17.3 – 12.9 15.5 18.2 – 26.6 – 18.1 – – – – 1-1/2" – 14.3 17.4 20.6 15.1 18.2 21.5 – 31.7 – 21.5 – – – – 1-3/4" 16.5 – 20.1 23.9 17.4 – 21.0 24.8 – 36.8 – 24.9 – – – – 2" 18.7 – 22.9 27.2 19.6 – 23.7 28.1 – 41.9 – 28.3 – – – – 2-1/4" 22.9 – 25.6 30.5 24.3 – 26.5 31.4 – 47.0 – 31.7 – – – – 2-1/2" 23.2 – 28.4 33.8 24.0 – 29.2 34.7 52.1 – 35.1 – 38.5 – 26.6 3" 27.5 – 33.9 40.4 28.6 – 34.3 41.3 62.3 – 41.9 – 43.9 – 30.4 – 3-1/2" 29.6 – 39.4 47.0 30.0 – 40.2 47.9 – – – – 49.4 – 34.1 – 4" 36.3 – 44.9 53.6 37.4 – 45.7 54.4 – – – – 54.8 – 37.8 – 4-1/2" 40.7 – 50.4 60.2 41.8 – 51.2 61.0 – – – – 60.3 – 41.5 – 5" 45.0 – 55.9 66.7 46.2 – 56.7 67.6 – – – – 65.7 – 45.2 – LBS PER SQ FT McNICHOLS® Heavy-Duty Rectangular Bar Grating Designed for maximum load-bearing applications, Heavy-Duty handles heavier loads with a thicker bar. Ideal for vehicular wheel traffic applications. SERIES GHB, GHB-2 MATERIAL M ill Finish: Carbon Steel (CS) (Plain, Powder Coated Black), Galvanized Steel (GV), Stainless Steel (SS) SURFACE Smooth, Serrated | GRIP TIGHT® SIZE (W x L) 2 4” x 240”, 24” x 288”, 36” x 240”, 36” x 288”, Other Sizes, Cut Sizes, Stair Treads Available SERIES PEDS & TREADS® MATERIAL M ill Finish: Carbon Steel (CS) (Plain, Powder Coated Black), Galvanized Steel (GV) SURFACE Smooth (Serrated, GRIP TIGHT® – Please Inquire) SIZE (W x L) 3 6” x 96” CUSTOM ORDER CUSTOM ORDER
BAR GRATING 9 mcnichols.com McNICHOLS® Heavy-Duty Welded Bar Grating, GHB-250 (19-W-4), No. 6625140132 Grating Description: GHB-250 (19-W-4) Bar Grating names follow a standard format. Each part of the name provides key details about the Grating’s structure. The guide below breaks down the naming convention with an example to help you quickly interpret specifications. 19-W-4 GHB-250 Grating Type Description 19 W 4 GHB 250 19/16” (1-3/16”) BB Spacing Welded Construction Type 4” CB Spacing Grating Heavy Bar Series Type 2-1/2” BB Height Visit mcnichols.com to browse our entire inventory of GHB and PEDS & TREADS® Heavy-Duty Bar Grating. Carbon Steel Stainless Steel Galvanized Steel Black Powder Coat FINISHES SIDE VIEW CB Spacing BB Height END VIEW CB BB Thickness BB Spacing SURFACE TYPES Smooth Serrated GRIP TIGHT® CUSTOM ORDER
10 855.374.4250 BB HGT AL AL AL AL 3/4" – – – – – – – – 1" 1.9 2.6 2.0 2.8 1.9 2.6 2.2 2.9 1-1/4" 2.1 3.2 2.4 3.5 2.3 3.2 2.6 3.5 1-1/2" 2.5 3.8 2.8 3.9 2.8 3.9 3.2 4.3 1-3/4" – 4.3 – 4.4 – 4.5 – 4.9 2" – 4.9 – 5.0 – 5.1 – 5.5 2-1/4" – 5.3 – 5.6 – 5.7 – 6.1 2-1/2" – 5.8 – 6.1 – 6.3 – 6.7 SERIES, SPACING GAL 19-S-4 GAL 19-S-2 SFT 19-SF-4 SFT-2 19-SF-2 BB SPACING 1-3/16” 1-3/16” 1-3/16" 1-3/16" CB SPACING 4” 2” 4” 2” BB THK 1/8” 3/16” 1/8” 3/16" 1/8” 3/16” 1/8” 3/16” SPACE B/T BB 1-1/16” 1” 1-1/16” 1” 1-1/16” 1” 1-1/16” 1” OA % 85% 80% 80% 75% 85% 80% 80% 75% PRODUCT OPTIONS LBS PER SQ FT BB HGT BB THK LD/DF 12" 18" 24" 30" 36" 42" 48" 54" 60" 66" 72" 78" 84" 90" 96" GAL, GAL-2, SFT, SFT-2 ALUMINUM LOAD TABLE 3/4" 1/8" U 947 421 237 152 105 77 59 47 38 31 26 22 19 17 15 D 0.048 0.108 0.192 0.301 0.431 0.586 0.765 0.977 1.204 1.438 1.708 1.990 2.312 2.726 3.114 C 474 316 237 189 158 135 118 105 95 86 79 73 68 63 59 D 0.038 0.086 0.154 0.239 0.346 0.469 0.612 0.776 0.963 1.160 1.384 1.625 1.891 2.155 2.449 3/4" 3/16" U 1421 631 355 227 158 116 89 70 57 47 39 34 29 25 22 D 0.048 0.108 0.192 0.300 0.432 0.588 0.770 0.970 1.204 1.453 1.708 2.050 2.352 2.672 3.044 C 710 474 355 284 237 203 178 158 142 129 118 109 101 95 89 D 0.038 0.086 0.154 0.240 0.346 0.470 0.616 0.778 0.959 1.160 1.378 1.618 1.873 2.166 2.463 1" 1/8" U 1684 748 421 269 187 137 105 83 67 56 47 40 34 30 26 D 0.036 0.081 0.144 0.225 0.324 0.439 0.574 0.727 0.895 1.095 1.302 1.526 1.744 2.028 2.276 C 842 561 421 337 281 241 211 187 168 153 140 130 120 112 105 D 0.029 0.065 0.115 0.180 0.259 0.353 0.462 0.583 0.718 0.870 1.034 1.221 1.407 1.615 1.838 1" 3/16" U 2526 1123 632 404 281 206 158 125 101 84 70 60 52 45 39 D 0.036 0.081 0.144 0.225 0.324 0.440 0.576 0.730 0.900 1.095 1.293 1.526 1.779 2.029 2.276 C 1263 842 632 505 421 361 316 281 253 230 211 194 180 168 158 D 0.029 0.065 0.115 0.180 0.259 0.353 0.461 0.584 0.721 0.872 1.039 1.215 1.408 1.616 1.844 1-1/4" 1/8" U 2631 1169 658 421 292 215 164 130 105 87 73 62 54 47 41 D 0.029 0.065 0.115 0.180 0.259 0.353 0.459 0.583 0.718 0.871 1.035 1.211 1.419 1.627 1.838 C 1316 877 658 526 439 376 329 292 263 239 219 202 188 175 164 D 0.023 0.052 0.092 0.144 0.208 0.282 0.369 0.466 0.576 0.696 0.828 0.971 1.129 1.293 1.470 1-1/4" 3/16" U 3947 1754 987 632 439 322 247 195 158 130 110 93 81 70 62 D 0.029 0.065 0.115 0.180 0.259 0.353 0.461 0.583 0.720 0.868 1.040 1.211 1.419 1.616 1.853 C 1974 1316 987 789 658 564 493 439 395 359 329 304 282 263 247 D 0.023 0.052 0.092 0.144 0.207 0.282 0.368 0.467 0.576 0.697 0.830 0.975 1.129 1.295 1.476 1-1/2" 1/8" U 3790 1684 947 606 421 309 237 187 152 125 105 90 77 67 59 D 0.024 0.054 0.096 0.150 0.216 0.294 0.384 0.486 0.602 0.724 0.862 1.017 1.171 1.342 1.530 C 1895 1263 947 758 632 541 474 421 379 345 316 292 271 253 237 D 0.019 0.043 0.077 0.120 0.173 0.235 0.307 0.389 0.480 0.582 0.692 0.813 0.942 1.081 1.229 1-1/2" 3/16" U 5684 2526 1421 909 632 464 355 281 227 188 158 135 116 101 89 D 0.024 0.054 0.096 0.150 0.216 0.294 0.384 0.487 0.599 0.726 0.865 1.017 1.176 1.349 1.539 C 2842 1895 1421 1137 947 812 711 632 568 517 474 437 406 379 355 D 0.019 0.043 0.077 0.120 0.173 0.235 0.307 0.389 0.480 0.581 0.692 0.811 0.941 1.080 1.228 1-3/4" 3/16" U 7737 3439 1934 1238 860 632 484 382 309 256 215 183 158 138 121 D 0.021 0.046 0.082 0.129 0.185 0.252 0.329 0.417 0.514 0.623 0.741 0.869 1.009 1.161 1.318 C 3868 2579 1934 1547 1289 1105 967 860 774 703 645 595 553 516 484 D 0.016 0.037 0.066 0.103 0.148 0.202 0.263 0.333 0.412 0.498 0.593 0.695 0.807 0.926 1.054 2" 3/16" U 10106 4491 2526 1617 1123 825 632 499 404 334 281 239 206 180 158 D 0.018 0.040 0.072 0.113 0.162 0.221 0.288 0.364 0.450 0.544 0.649 0.760 0.881 1.014 1.153 C 5053 3369 2526 2021 1684 1444 1263 1123 1011 919 842 777 722 674 632 D 0.014 0.032 0.058 0.090 0.130 0.176 0.230 0.292 0.360 0.436 0.518 0.608 0.706 0.810 0.922 2-1/4" 3/16" U 12790 5684 3197 2046 1421 1044 799 632 512 423 355 303 261 227 200 D 0.016 0.036 0.064 0.100 0.144 0.196 0.256 0.324 0.400 0.484 0.576 0.677 0.784 0.899 1.025 C 6395 4263 3197 2558 2132 1827 1599 1421 1279 1163 1066 984 914 853 799 D 0.013 0.029 0.051 0.080 0.115 0.157 0.205 0.259 0.320 0.387 0.461 0.541 0.628 0.720 0.819 2-1/2" 3/16" U 15790 7018 3947 2526 1754 1289 987 780 632 522 439 374 322 281 247 D 0.014 0.032 0.058 0.090 0.130 0.176 0.230 0.292 0.360 0.436 0.519 0.609 0.705 0.811 0.923 C 7895 5263 3947 3158 2632 2256 1974 1754 1579 1435 1316 1215 1128 1053 987 D 0.012 0.026 0.046 0.072 0.104 0.141 0.184 0.233 0.288 0.348 0.415 0.487 0.565 0.648 0.737 BEARING BAR PANEL WIDTHS NO. BARS GAL, GAL-2 SFT, SFT-2 1/8" 3/16" 1/8" 3/16" 2 1-5/16" 1-3/8" 1-5/16" 1-3/8" 3 2-1/2" 2-9/16" 2-1/2" 2-9/16" 4 3-11/16" 3-3/4" 3-11/16" 3-3/4" 5 4-7/8" 4-15/16" 4-7/8" 4-15/16" 6 6-1/16" 6-1/8" 6-1/16" 6-1/8" 7 7-1/4" 7-5/16" 7-1/4" 7-5/16" 8 8-7/16" 8-1/2" 8-7/16" 8-1/2" 9 9-5/8" 9-11/16" 9-5/8" 9-11/16" 10 10-13/16" 10-7/8" 10-13/16" 10-7/8" 11 12" 12-1/16" 12" 12-1/16" 12 13-3/16" 13-1/4" 13-3/16" 13-1/4" 13 14-3/8" 14-7/16" 14-3/8" 14-7/16" 14 15-9/16" 15-5/8" 15-9/16" 15-5/8" 15 16-3/4" 16-13/16" 16-3/4" 16-13/16" 16 17-15/16" 18" 17-15/16" 18" 17 19-1/8" 19-3/16" 19-1/8" 19-3/16" 18 20-5/16" 20-3/8" 20-5/16" 20-3/8" 19 21-1/2" 21-9/16" 21-1/2" 21-9/16" 20 22-11/16" 22-3/4" 22-11/16" 22-3/4" 21 23-7/8" 23-15/16" 23-7/8" 23-15/16" 22 25-1/16" 25-1/8" 25-1/16" 25-1/8" 23 26-1/4" 26-5/16" 26-1/4" 26-5/16" 24 27-7/16" 27-1/2" 27-7/16" 27-1/2" 25 28-5/8" 28-11/16" 28-5/8" 28-11/16" 26 29-13/16" 29-7/8" 29-13/16" 29-7/8" 27 31" 31-1/16" 31" 31-1/16" 28 32-3/16" 32-1/4" 32-3/16" 32-1/4" 29 33-3/8" 33-7/16" 33-3/8" 33-7/16" 30 34-9/16" 34-5/8" 34-9/16" 34-5/8" 31 35-3/4" 35-13/16" 35-3/4" 35-13/16" Common widths listed in gray. All others are cut sizes. Panels measured from outside edges of bars. Panels up to 48" wide by custom order. Wider areas covered by two or more pieces of Grating. U - Uniform Load - Lbs./Sf. D - Deflection in Inches C - Concentrated Load - Lbs./Ft. of Width at Mid-Span | Aluminum: Fs - 12,000 PSI E - 10,000,000 PSI | Additional information at mcnichols.com. Spans listed in table are clear (inside structural supports). Values to left of bolded black line produce deflection ≤ 1/4" under a uniform load of 100 Lbs./Sf., allowing for safe pedestrian comfort. Values to right apply to other load types at discretion of engineer. For 1" height and taller serrated surface bars, subtract 1/4" from bar height and reference that loading information in table (e.g., 1-1/2" height x 3/16" thick serrated bar has same loading as 1-1/4" height x 3/16" thick smooth bar). Technical information is theoretical. McNICHOLS is not liable for improper evaluation or use of Bar Grating. McNICHOLS® Swage-Locked Rectangular Bar Grating Made from Aluminum, lightweight, and corrosion-resistant, with swaged cross bars for added strength. SERIES GAL, GAL-2, SGAL, SGAL-2 MATERIAL M ill Finish: Aluminum (AL) SURFACE Smooth, Serrated | GRIP TIGHT® SIZE (W x L) 2 4” x 240”, 24” x 288”, 36” x 144”, 36” x 240”, 36” x 288”, Other Sizes, Cut Sizes, Stair Treads Available SERIES SFT, SFT-2 (Cross Bars Flush w/ Top of Bearing Bars) MATERIAL M ill Finish: Aluminum (AL) SURFACE Smooth, Serrated | GRIP TIGHT® SIZE (W x L) 2 4” x 240”, 24” x 288”, 36” x 240”, 36” x 288”, Other Sizes, Cut Sizes, Stair Treads Available CUSTOM ORDER CUSTOM ORDER
BAR GRATING 11 mcnichols.com McNICHOLS® Swage-Locked Bar Grating, GAL-100 (19-S-4), No. 67013153 Grating Description: GAL-100 (19-S-4) Bar Grating names follow a standard format. Each part of the name provides key details about the Grating’s structure. The guide below breaks down the naming convention with an example to help you quickly interpret specifications. 19-S-4 GAL-100 Grating Type Description 19 S 4 GAL 100 19/16” (1-3/16”) BB Spacing Swage-Locked Construction Type 4” CB Spacing Grating Aluminum Series Type 1” BB Height Visit mcnichols.com to browse our entire inventory of GAL and SFT Swage-Locked Bar Grating. Aluminum END VIEW SIDE VIEW FINISHES BB Thickness BB Spacing CB CB Spacing BB Height SURFACE TYPES Smooth Serrated GRIP TIGHT® CUSTOM ORDER
12 855.374.4250 McNICHOLS® Swage-Locked I-Bar Grating Made of Aluminum with I-shaped bearing bars, it is ideal for chemical environments and offers a high strength-to-weight ratio. SERIES GIA, GIA-2 MATERIAL M ill Finish: Aluminum (AL) SURFACE Grooved | GRIP TIGHT® SIZE (W x L) 2 4” x 240”, 24” x 288”, 36” x 240”, 36” x 288”, Other Sizes, Cut Sizes, Stair Treads Available LBS PER SQ FT BB HGT AL 1" 1.9 2.1 1-1/4" 2.3 2.5 1-1/2" 2.6 2.8 1-3/4" 3.0 3.3 2" 3.4 3.7 2-1/4" 3.8 4.0 2-1/2" 4.0 4.2 PRODUCT OPTIONS SERIES, SPACING GIA 19-SI-4 GIA-2 19-SI-2 BB SPACING 1-3/16” 1-3/16” CB SPACING 4” 2” BB THK/TOP FLANGE WD 1/4" 1/4” SPACE B/T BB 15/16” 15/16” OA % 75% 71% BB HGT BB THK LD/DF 12" 18" 24" 30" 36" 42" 48" 54" 60" 66" 72" 78" 84" 90" 96" GIA, GIA-2 ALUMINUM LOAD TABLE 1" 1/4" U 2526 1123 632 404 281 206 158 125 101 84 70 60 52 45 39 D 0.036 0.081 0.144 0.225 0.324 0.440 0.576 0.730 0.900 1.095 1.293 1.526 1.779 2.029 2.276 C 1263 842 632 505 421 361 316 281 253 230 211 194 180 168 158 D 0.029 0.065 0.115 0.180 0.259 0.353 0.461 0.584 0.721 0.872 1.039 1.215 1.408 1.616 1.844 1-1/4" 1/4" U 3947 1754 987 632 439 322 247 195 158 130 110 93 81 70 62 D 0.029 0.065 0.115 0.180 0.259 0.353 0.461 0.583 0.720 0.868 1.040 1.211 1.419 1.616 1.853 C 1974 1316 987 789 658 564 493 439 395 359 329 304 282 263 247 D 0.023 0.052 0.092 0.144 0.207 0.282 0.368 0.467 0.576 0.697 0.830 0.975 1.129 1.295 1.476 1-1/2" 1/4" U 5684 2526 1421 909 632 464 355 281 227 188 158 135 116 101 89 D 0.024 0.054 0.096 0.150 0.216 0.294 0.384 0.487 0.599 0.726 0.865 1.017 1.176 1.349 1.539 C 2842 1895 1421 1137 947 812 711 632 568 517 474 437 406 379 355 D 0.019 0.043 0.077 0.120 0.173 0.235 0.307 0.389 0.480 0.581 0.692 0.811 0.941 1.080 1.228 1-3/4" 1/4" U 7737 3439 1934 1238 860 632 484 382 309 256 215 183 158 138 121 D 0.021 0.046 0.082 0.129 0.185 0.252 0.329 0.417 0.514 0.623 0.741 0.869 1.009 1.161 1.318 C 3868 2579 1934 1547 1289 1105 967 860 774 703 645 595 553 516 484 D 0.016 0.037 0.066 0.103 0.148 0.202 0.263 0.333 0.412 0.498 0.593 0.695 0.807 0.926 1.054 2" 1/4" U 10106 4491 2526 1617 1123 825 632 499 404 334 281 239 206 180 158 D 0.018 0.040 0.072 0.113 0.162 0.221 0.288 0.364 0.450 0.544 0.649 0.760 0.881 1.014 1.153 C 5053 3369 2526 2021 1684 1444 1263 1123 1011 919 842 777 722 674 632 D 0.014 0.032 0.058 0.090 0.130 0.176 0.230 0.292 0.360 0.436 0.518 0.608 0.706 0.810 0.922 2-1/4" 1/4" U 12790 5684 3197 2046 1421 1044 799 632 512 423 355 303 261 227 200 D 0.016 0.036 0.064 0.100 0.144 0.196 0.256 0.324 0.400 0.484 0.576 0.677 0.784 0.899 1.025 C 6395 4263 3197 2558 2132 1827 1599 1421 1279 1163 1066 984 914 853 799 D 0.013 0.029 0.051 0.080 0.115 0.157 0.205 0.259 0.320 0.387 0.461 0.541 0.628 0.720 0.819 2-1/2" 1/4" U 15790 7018 3947 2526 1754 1289 987 780 632 522 439 374 322 281 247 D 0.014 0.032 0.058 0.090 0.130 0.176 0.230 0.292 0.360 0.436 0.519 0.609 0.705 0.811 0.923 C 7895 5263 3947 3158 2632 2256 1974 1754 1579 1435 1316 1215 1128 1053 987 D 0.012 0.026 0.046 0.072 0.104 0.141 0.184 0.233 0.288 0.348 0.415 0.487 0.565 0.648 0.737 U - Uniform Load - Lbs./Sf. D - Deflection in Inches C - Concentrated Load - Lbs./Ft. of Width at Mid-Span Fs - 12,000 PSI E - 10,000,000 PSI | Additional information at mcnichols.com. Spans listed in table are clear (inside structural supports). Values to left of bolded black line produce deflection < 1/4" under a uniform load of 100 Lbs./Sf., allowing for safe pedestrian comfort. Values to right apply to other load types at discretion of engineer. Technical information is theoretical. McNICHOLS is not liable for improper evaluation or use of Bar Grating. GIA SERIES PANEL WIDTHS NO. BARS GIA, GIA-2 2 1-7/16" 3 2-5/8" 4 3-13/16" 5 5" 6 6-3/16" 7 7-3/8" 8 8-9/16" 9 9-3/4" 10 10-15/16" 11 12-1/8" 12 13-5/16" 13 14-1/2" 14 15-11/16" 15 16-7/8" 16 18-1/16" 17 19-1/4" 18 20-7/16" 19 21-5/8" 20 22-13/16" 21 24" 22 25-3/16" 23 26-3/8" 24 27-9/16" 25 28-3/4" 26 29-15/16" 27 31-1/8" 28 32-5/16" 29 33-1/2" 30 34-11/16" 31 35-7/8" Common widths listed in gray. All others are cut sizes. Panels measured from outside edges of bars. Wider areas covered by two or more pieces of Grating. APPLICATION HIGHLIGHT: SECURITY FENCING Bar Grating provides the strength and durability needed for secure fencing while maintaining visibility and airflow. The result is a secure, low-maintenance solution with lasting performance and a distinctive aesthetic. McNICHOLS® Swage-Locked Rectangular Bar Grating, No. 67011853 CUSTOM ORDER
BAR GRATING 13 mcnichols.com McNICHOLS® Swage-Locked I-Bar Grating, GIA-150 (19-SI-4), No. 6702317734 Grating Description: GIA-150 (19-SI-4) Bar Grating names follow a standard format. Each part of the name provides key details about the Grating’s structure. The guide below breaks down the naming convention with an example to help you quickly interpret specifications. 19-SI-4 GIA-150 Grating Type Description 19 SI 4 GIA 150 19/16” (1-3/16”) BB Spacing Swage-Locked I-Bar Construction Type 4” CB Spacing Grating I-Bar Aluminum Series Type 1-1/2” BB Height Visit mcnichols.com to browse our entire inventory of GIA and SGIA Swage-Locked I-Bar Grating. Aluminum Grooved SURFACE TYPES FINISHES CB Spacing BB Height SIDE VIEW BB Thickness BB Spacing CB END VIEW GRIP TIGHT® CUSTOM ORDER
14 855.374.4250 PRODUCT OPTIONS SERIES, SPACING TB-940 19-S-4 TB-626 19-S-4 BB SPACING 1-3/16” 1-3/16” CB SPACING 4” 4” TOP FLANGE WD 0.940" 0.626” SPACE B/T TOP FLANGES 0.2475" (ADA) 0.5615" OA % 21% 47% LBS PER SQ FT BB HGT AL AL 1" 3.0 2.7 1-1/4" 4.2 3.3 1-1/2" 4.4 3.6 2 5.0 4.1 BB HGT TF WD LD/DF 12" 18" 24" 30" 36" 42" 48" 54" 60" 66" 72" 78" 84" 90" 96" TB-940 ALUM LOAD TABLE 1" 0.940" U 4204 1868 1051 673 467 343 263 208 168 139 117 100 86 75 66 D 0.031 0.070 0.125 0.195 0.281 0.382 0.500 0.633 0.779 0.944 1.125 1.325 1.532 1.761 2.006 C 2102 1401 1051 841 701 601 526 467 420 382 350 323 300 280 263 D 0.025 0.056 0.100 0.156 0.225 0.306 0.400 0.505 0.623 0.755 0.898 1.053 1.222 1.403 1.599 1-1/4" 0.940" U 6953 3090 1738 1112 773 568 435 343 278 230 193 165 142 124 109 D 0.024 0.054 0.097 0.151 0.218 0.297 0.387 0.489 0.605 0.732 0.870 1.025 1.186 1.365 1.553 C 3476 2318 1738 1391 1159 993 869 773 695 632 579 535 497 464 435 D 0.019 0.044 0.077 0.121 0.174 0.237 0.310 0.392 0.484 0.585 0.696 0.818 0.949 1.090 1.240 1-1/2" 0.940" U 9378 4168 2344 1500 1042 766 586 463 375 310 260 222 191 167 147 D 0.020 0.046 0.082 0.128 0.184 0.251 0.327 0.414 0.512 0.619 0.736 0.865 1.001 1.153 1.314 C 4689 3126 2344 1876 1563 1340 1172 1042 938 853 781 721 670 625 586 D 0.016 0.037 0.065 0.102 0.147 0.201 0.262 0.332 0.410 0.496 0.589 0.692 0.803 0.921 1.048 2" 0.940" U 14875 6611 3719 2380 1653 1214 930 735 595 492 413 352 304 264 232 D 0.016 0.035 0.063 0.098 0.141 0.192 0.251 0.318 0.392 0.475 0.565 0.663 0.770 0.881 1.003 C 7438 4958 3719 2975 2479 2125 1859 1653 1488 1352 1240 1144 1063 992 930 D 0.013 0.028 0.050 0.078 0.113 0.154 0.201 0.254 0.314 0.380 0.452 0.530 0.616 0.707 0.804 TB-626 ALUM LOAD TABLE 1" 0.626" U 3962 1761 990 634 440 323 248 196 158 131 110 94 81 70 62 D 0.034 0.076 0.136 0.212 0.305 0.415 0.544 0.688 0.846 1.027 1.221 1.437 1.666 1.897 2.175 C 1981 1321 990 792 660 566 495 440 396 360 330 305 283 264 248 D 0.027 0.061 0.109 0.170 0.244 0.333 0.434 0.549 0.678 0.821 0.977 1.148 1.330 1.526 1.740 1-1/4" 0.626" U 6063 2695 1516 970 674 495 379 299 243 200 168 144 124 108 95 D 0.027 0.061 0.108 0.169 0.243 0.331 0.432 0.546 0.676 0.815 0.969 1.145 1.326 1.522 1.733 C 3032 2021 1516 1213 1011 866 758 674 606 551 505 466 433 404 379 D 0.022 0.049 0.086 0.135 0.194 0.265 0.346 0.438 0.540 0.653 0.777 0.912 1.058 1.214 1.382 1-1/2" 0.626" U 8084 3593 2021 1293 898 660 505 399 323 267 225 191 165 144 126 D 0.023 0.051 0.091 0.142 0.205 0.279 0.364 0.461 0.569 0.689 0.822 0.961 1.117 1.284 1.455 C 4042 2695 2021 1617 1347 1155 1011 898 808 735 674 622 577 539 505 D 0.018 0.041 0.073 0.114 0.164 0.223 0.292 0.369 0.455 0.551 0.657 0.770 0.892 1.025 1.166 2" 0.626" U 12692 5641 3173 2031 1410 1036 793 627 508 420 353 300 259 226 198 D 0.017 0.039 0.069 0.108 0.156 0.212 0.277 0.351 0.434 0.525 0.625 0.731 0.849 0.977 1.108 C 6346 4231 3173 2538 2115 1813 1587 1410 1269 1154 1058 976 907 846 793 D 0.014 0.031 0.055 0.087 0.125 0.170 0.222 0.281 0.347 0.420 0.499 0.586 0.680 0.780 0.887 SAFE-T-GRID® PANEL WIDTHS NO. BARS TB-940 TB-626 2 2.128" 1.814" 3 3.315" 3.001" 4 4.503" 4.189" 5 5.690" 5.376" 6 6.878" 6.564" 7 8.065" 7.751" 8 9.253" 8.939" 9 10.440" 10.126" 10 11.628" 11.314" 11 12.815" 12.501" 12 14.003" 13.689" 13 15.190" 14.876" 14 16.378" 16.064" 15 17.565" 17.251" 16 18.753" 18.439" 17 19.940" 19.626" 18 21.128" 20.814" 19 22.315" 22.001" 20 23.503" 23.189" 21 24.690" 24.376" 22 25.878" 25.564" 23 27.065" 26.751" 24 28.253" 27.939" 25 29.440" 29.126" 26 30.628" 30.314" 27 31.815" 31.501" 28 33.003" 32.689" 29 34.190" 33.876" 30 35.378" 35.064" 31 36.565" 36.250" Common widths listed in gray. All others are cut sizes. Panels measured from outside of edges of bars. Wider areas covered by two or more pieces of Grating. U - Uniform Load - Lbs./Sf. D - Deflection in Inches C - Concentrated Load - Lbs./Ft. of Width at Mid-Span Fs - 12,000 PSI E - 10,000,000 PSI | Additional information at mcnichols.com. Spans listed in table are clear (inside structural supports). Values to left of bolded black line produce deflection < 1/4" under a uniform load of 100 Lbs./Sf., allowing for safe pedestrian comfort. Values to right apply to other load types at discretion of engineer. TB-940 Series has ADA-compliant spacing. Technical information is theoretical. McNICHOLS is not liable for improper evaluation or use of Bar Grating. McNICHOLS SAFE-T-GRID® Swage-Locked T-Bar Grating Features extruded T-shaped bearing bars with cross bars locked by swaging, suitable for pedestrian traffic. SERIES TB-940 – SAFE-T-GRID® MATERIAL M ill Finish: Aluminum (AL) SURFACE Grooved | GRIP TIGHT® SIZE (W x L) 3 6.565” x 288”, Cut Sizes, Stair Treads Available SERIES TB-626 – SAFE-T-GRID® MATERIAL M ill Finish: Aluminum (AL) SURFACE Grooved | GRIP TIGHT® SIZE (W x L) 3 6.250” x 288”, Cut Sizes, Stair Treads Available ADA COMPLIANT BAR GRATING Scan the QR code to view a comprehensive list of ADA Compliant Bar Grating items. McNICHOLS® Bar Grating items qualify for ADA compliant applications when the direction of the bearing bars (span) is installed perpendicular to the dominant direction of travel. CUSTOM ORDER CUSTOM ORDER
